Signals of RAILSIMâ Version USA 1.28

from an original "Word" document ã1999 by Jens Schubert.
This html conversion is by the webmaster of this site ã2000
permission is given to copy for non-commercial purposes



1. "Normal Speed, Clear": max. speed allowed (track speed, train speed)

...at next signal:

clear limited medium slow stop

2nd next Signal shows :

      stop limited, medium or slow

2. "Limited Speed, Clear": max. speed 45 mph

...at next signal:

clear limited medium slow stop

3. "Medium Speed, Clear": max. speed 30 mph

...at next signal:

clear limited; medium slow stop

4. "Slow Speed, Clear": max. speed 15 mph (RAILSIM allows 20 mph)

...at next signal:

clear limited medium slow stop

4a. "Restricted": max. speed 20mph or less

...at next signal:

20mph or less

5."Stop": DO NOT PASS !

...at this signal:

Absolute stop.

6. Other signal appearances

lower light can be missing.
second light can be to right of post.
"dwarf signals" (in tunnels only).

absolute permissive dwarf
